Bite Type Hydraulic Bulkhead Fittings Adapter 6D Metric Thread 24 Degree H.T.

Bite Type Hydraulic Bulkhead Fittings Adapter 6D Metric Thread 24 Degree H.T.
Bite Type Hydraulic Bulkhead Fittings Adapter 6D Metric Thread 24 Degree H.T.

Large Image :  Bite Type Hydraulic Bulkhead Fittings Adapter 6D Metric Thread 24 Degree H.T.

Product Details:
Place of Origin: Zhejiang, China (Mainland)
Brand Name: DUOLI
Model Number: SV(6D)
Payment & Shipping Terms:
Minimum Order Quantity: 200pcs
Packaging Details: standard exporting package or as per customers' requests.
Delivery Time: within 30 days or as per customers' requirement.
Payment Terms: T/T
Supply Ability: 1000pcs/month

Bite Type Hydraulic Bulkhead Fittings Adapter 6D Metric Thread 24 Degree H.T.

Description
Material: Carbon Steel Color: White
Technics: CNC PROCESSING Connection: 24 DEGREE TAPPER
Brand Name: DUOLI
High Light:

hydraulic pipe connections

,

steel flare fittings

6D metric male 24 degree H.T. hydraulic bulkhead bite type tube fittings





The sleeve type pipe joint assembly:

(1) pre assembled, sleeve type pipe joint pre assembly of the most important link, directly affect the reliability of the seal. A dedicated preprocessor is usually required. The small diameter can be pre joint in a vise. The concrete method is to use a joint as the mother's body and press the nut and the sleeve onto the tube. The utility model mainly comprises a sleeve type through pipe joint, a clamping sleeve type end through connection head, a clamping sleeve type three way pipe joint and other patterns. I found that even if the same manufacturer of a batch of goods, the cone of these joints on the depth of the hole is often different, resulting in a leak, and this problem is often neglected. The correct approach is to connect the end of the pipe with what kind of joint, and the corresponding connection ends are prefabricated with the same type of joint, so that the leakage problem can be avoided to the maximum extent.

The ends of the pipe shall be flush. The pipe should be flush in sawing grinding wheel and other tools, and burr cleaning and blowing with high pressure air before use.

When installing, the coaxiality of pipe and joint body should be kept as far as possible. If the pipe deflection is too large, it will cause sealing failure.

If the pre loading force is unfavorable, the inner edge of the ambassador card sleeve is just inserted into the outer wall of the pipe, and the clamping sleeve should not be deformed obviously. When the pipeline connection, and then according to the specified tightening force assembly. Phi 6-1 card sleeve tightening force is 64-1 15N, 16 MMR 259n, Phi Phi 18mm for 450n. If the sleeve is badly deformed at pre assembly, it will lose its sealing effect.

(2) prohibit adding sealant and other fillers. Some people in order to obtain better sealing effect, in the card cover with sealant, the result of sealant is poured into the hydraulic system, causing hydraulic components, such as plugging holes.

(3) when connecting the pipe, the pipe should have enough deformation allowance to avoid drawing the tube.

(4) when connecting the pipeline, the lateral force should be avoided, and the lateral force will cause the seal to be too tight.

(5) when connecting pipelines, should be a one-time good, avoid repeated disassembly, otherwise it will make poor sealing performance. Jacket type pipe joint installation



Product Description

Bite Type Hydraulic Bulkhead Fittings Adapter 6D Metric Thread 24 Degree H.T. 0



Packaging & Delivery

OEM Packing
We can make customer's brand packing and we will protect your brand,will not show others' your packing.
About package
1. After order is placed,we will confirm with customer all the printing details including box design,shippment mark,pallet mark ect

2. All insturction will be follow during the order is produced

3. Before shippment,we will take photoes for customer for approval
About Shippment
Shipments for small sample order are via DHL,TNT,UPS, or Fedex etc ,normal order is Via Sea from ningbo port or shanghai port.If you need other port,you should tell us before ordering as the cost is different.
About the delivery time
Standard lead time is about 7-30 days or according to the order quantity
We provide both quality product and good service, ensuring an excellent customer experience. We are committed to solve any problem associated with our products. We are looking forward to the opportunity of serving you.





Our main products: Hose Assembly, Swaged Hose Fittings, Metric Thread O-ring Face Seal Fittings, Metric Thread Bite Type Tube Fittings, Metric Thread 74 degree Cone Flared Tube Fittings, BSP Thread 60 degree Cone Fittings, BSPT Thread Fittings, NPT Thread Fittings, JIC 74 degree Cone Flared Tube Fittings, ORFS Fittings, Japanese Metric Thread 60 degree Cone Fittings, Japanese BSP Thread 60 degree Cone Fittings, NPSM Fittings, ISO 6162 Flange Fittings and SAE Staple-lok Fittings.



Standard: JIC JIS UNF BSP DIN and so on.



FAQ



1. Q: What’s your delivery time?


A: The time of delivery is 30 days.

2. Q: What’s your payment term?

A: T/T.

3. Q:Can you provide samples?

A: Yes, we can provide samples if we have stock, but the express should be paid by yourside.
